TRUMA ULTRAHEAT* heating system
Thetemperaturelevel(1-6)andperformancelevel(inwatts)aredis-
played in the menu for the electric auxiliary heating system. The
lowermenuiconisshowningreenwhentheheatingsystemisin
operation.
Nexttothisicon,thevalue
ON = on or
OFF=heatingsystemisnotinoperation(whiteicon)isshown.
Theheatingsystemisactivatedordeactivatedusingthe“On/O”
functioninmenubarC.
Theiconsfortemperatureandperformancelevelaswellastheinfo
iconshowninmenubarCleadtofurthersubmenusbymeansof
thesoftkeysorsettingthecontrolknobtoaselection.
6
500 W
6
500 W
6
500 W
Info menu
  Informationonthedevicemanufacturerisshownhere.
Regulating the performance level
  Levels500W/1000W/2000Wcanbeselected.
Regulating the temperature
Levelscanbeselectedfrom1–6(6=highesttemperaturelevel)
PleasealsoobservethedescriptionsinChapter 10.2.2
Electric auxiliary heating system.
Thesubmenusshifttothemainmenubymeansofthe“Back”func-
tion.Themainmenushiftstothemainmenuonthecontrolpanelby
meansofthe“Back”function.Afteroneminute,allmenusautoma-
ticallyshifttothemainmenuonthecontrolpanel.
Usethe“+/-”iconsorturnthecontrolknobtochangethedesired
value.Pressthecontrolknobtoconrmthechangedvalue.
