HT48R30A-1/HT48C30-1
Register
Reset
(Power-on)
RES
or LVR
Reset
WDT
Time-out
(Normal Operation)
WDT
Time-out
(HALT)
MP
- xxx xxxx - uuu uuuu - uuu uuuu - uuu uuuu
ACC xxxx xxxx uuuu uuuu uuuu uuuu uuuu uuuu
PCL 0000 0000 0000 0000 0000 0000 0000 0000
TBLP xxxx xxxx uuuu uuuu uuuu uuuu uuuu uuuu
TBLH
- - xx xxxx --uu uuuu --uu uuuu --uu uuuu
STATUS
--00 xxxx - - uu uuuu - - 1u uuuu - - 11 uuuu
INTC
--00 - 000 --00 - 000 --00 - 000 --uu - uuu
WDTS 0000 0111 0000 0111 0000 0111 uuuu uuuu
TMR xxxx xxxx xxxx xxxx xxxx xxxx uuuu uuuu
TMRC
00- 0 1000 00- 0 1000 00- 0 1000 uu- u uuuu
PA 1111 1111 1111 1111 1111 1111 uuuu uuuu
PAC 1111 1111 1111 1111 1111 1111 uuuu uuuu
PB 1111 1111 1111 1111 1111 1111 uuuu uuuu
PBC 1111 1111 1111 1111 1111 1111 uuuu uuuu
PC
--11 1111 --11 1111 --11 1111 - - uu uuuu
PCC
--11 1111 --11 1111 --11 1111 - - uu uuuu
PG
- - - - - 111 - - - - - 111 - - - - - 111 - - - - - uuu
PGC
- - - - - 111 - - - - - 111 - - - - - 111 - - - - - uuu
²u² stands for unchanged
²x² stands for unknown
²-² stands for unimplemented
62
I/O Type MCU
