HT48R70A-1/HT48C70-1
Register
Reset
(Power-on)
RES
or LVR
Reset
WDT
Time-out
(Normal Operation)
WDT
Time-out
(HALT)
MP0 xxxx xxxx uuuu uuuu uuuu uuuu uuuu uuuu
MP1 xxxx xxxx uuuu uuuu uuuu uuuu uuuu uuuu
ACC xxxx xxxx uuuu uuuu uuuu uuuu uuuu uuuu
PCL 0000 0000 0000 0000 0000 0000 0000 0000
TBLP xxxx xxxx uuuu uuuu uuuu uuuu uuuu uuuu
TBLH xxxx xxxx uuuu uuuu uuuu uuuu uuuu uuuu
STATUS
--00 xxxx - - uu uuuu - - 1u uuuu - - 11 uuuu
INTC
- 000 0000 - 000 0000 - 000 0000 - uuu uuuu
WDTS 0000 0111 0000 0111 0000 0111 uuuu uuuu
TMR0H xxxx xxxx xxxx xxxx xxxx xxxx uuuu uuuu
TMR0L xxxx xxxx xxxx xxxx xxxx xxxx uuuu uuuu
TMR0C
00- 01--- 00- 01--- 00- 01--- uu- uu---
TMR1H xxxx xxxx xxxx xxxx xxxx xxxx uuuu uuuu
TMR1L xxxx xxxx xxxx xxxx xxxx xxxx uuuu uuuu
TMR1C
00- 01--- 00- 01- - - 00- 01- - - uu- uu---
PA 1111 1111 1111 1111 1111 1111 uuuu uuuu
PAC 1111 1111 1111 1111 1111 1111 uuuu uuuu
PB 1111 1111 1111 1111 1111 1111 uuuu uuuu
PBC 1111 1111 1111 1111 1111 1111 uuuu uuuu
PC 1111 1111 1111 1111 1111 1111 uuuu uuuu
PCC 1111 1111 1111 1111 1111 1111 uuuu uuuu
PD 1111 1111 1111 1111 1111 1111 uuuu uuuu
PDC 1111 1111 1111 1111 1111 1111 uuuu uuuu
PE 1111 1111 1111 1111 1111 1111 uuuu uuuu
PEC 1111 1111 1111 1111 1111 1111 uuuu uuuu
PF 1111 1111 1111 1111 1111 1111 uuuu uuuu
PFC 1111 1111 1111 1111 1111 1111 uuuu uuuu
PG 1111 1111 1111 1111 1111 1111 uuuu uuuu
PGC 1111 1111 1111 1111 1111 1111 uuuu uuuu
²u² stands for unchanged
²x² stands for unknown
²-² stands for unimplemented
64
I/O Type MCU
