FRONT WHEEL/ SUSPENSION/
STEERING
13.
SERVICE INFORMATION 13-1
INVESTIGATION OF FAULTS 13-2
HANDLEBARS 13-3
FRONT WHEEL 13-8
FRONT SUSPENSION 13-14
STEERING COLUMN 13-22
CBX250
SERVICE INFORMATION
GENERAL INSTRUCTIONS
d
•To make services of repair and maintenance in the front wheel, suspension or steering column, to support the
motorcycle in a proper support. •
\Refer to Section 15 to obtain information to respect the brake system.
SPECIFICATIONS
Unit: mm
•Driving motorcycle with tires or damaged rays can affect the security. •A disk or brake pads
contaminated reduce the performance of braking. Discard the pills contaminated and wipe the disk
contaminated with a degreasing agent of brake of high quality.
TORQUE VALUES
Bolt top of the fork
22 N.m (2,2 kg.m)
Bolt Allen of the fork 20 N.m (2,0 kg.m) Apply locks chemistry to the thread
Bolt the support of the handlebars 24 N.m (2,4 kg.m)
Nut of the steering column 103 N.m (10,3 kg.m)
Adjustment Nut of the steering column Refer a la page 13-27 Bolt
fixing of the higher bridge 22 N.m (2,2 kg.m)
Bolt fixing of the bridge lower 39 N.m (3,9 kg.m)
Nut of the front axle 59 N.m (5,9 kg.m)
Bolt of disk on the front brake 42 N.m (4,2 kg.m)
Bolt ALOC: replace it with a new
Item Value Service Limit
Minimum Depth of tread depth
—
Until the wear
indicator
Tyre pressure (cold) Solamente pilot 225 kPa (2,25 kgf/cm
2
, 33 psi) —
Pilot y pasajero 225 kPa (2,25 kgf/cm
2
, 33 psi)
—
Twist of the axle — 0,20
Eccentricity of the rim Radial — 2,0
of the wheel
Axial — 2,0
Counterweight to the balance of the wheel — 60 g Max.
Slack Free length of spring 434,4 428,4
Twist of the tube of the fork — 0,20
Fluid recommended Fluid for suspension(ATF) —
Fluid Level 145 —
Capacity of fluid 296 ± 2,5 cm
3
—
Load of the bearing of the head of steering 0,98 – 1,47 N (0,10 – 0,15 kgf) —
