Honda 2010 CBX 250 User Manual

DISMANTLING AND INSTALLING THE ENGINE
6-2
TORQUE VALUES
Bolt to the plate of fixing the sprocket of transmission 10 N.m (1,0 kg.m)
Bolt/nut striker higher from the engine 44 N.m (4,4 kg.m)
Bolts/nuts from support striker superior of the engine 26 N.m (2,6 kg.m)
Bolt/nut lower front engine 44 N.m (4,4 kg.m)
Bolt/nut higher rear engine 44 N.m (4,4 kg.m)
Bolts of rear support higher engine 26 N.m (2,6 kg.m)
Bolt/nut lower rear engine 44 N.m (4,4 kg.m)
Bolts/nuts and bolts of upper stand of the engine 26 N.m (2,6 kg.m)
Bolt/nut superior engine 44 N.m (4,4 kg.m)
CBX250
Item Specifications
Weight of the engine (dry) 35,3 kg
Oil Capacity of the engine to dismantle 1,8 l
SPECIFICATIONS

Honda 2010 CBX 250 Specifications

General

Fuel System	Carburetor
Transmission	5-speed
Final Drive	Chain
Front Suspension	Telescopic fork
Front Brake	Single disc
Rear Brake	Drum
Engine Type	Air-cooled, 4-stroke, single cylinder, OHC
Bore x Stroke	73.0 mm x 59.5 mm
Ignition	CDI
Fuel Capacity	13 liters
