LIGHTS/METERS/SWITCHES
20-7
POSITION LIGHT
BULB REPLACEMENT
Pull out the position light bulb socket.
Remove the bulb from the bulb socket and replace it
with a new one.
Installation is in the reverse order of removal.
TURN SIGNAL LIGHT
BULB REPLACEMENT
Remove the screw, turn signal light lens and gasket.
While pushing the bulb in, turn it counterclockwise
to remove it from the bulb socket, and replace it
with a new one.
Install the gasket, turn signal light lens and screw.
Tighten the screw to the specified torque.
REMOVAL/INSTALLATION
FRONT
Remove the headlight plate (page 2-11).
Remove the nut and turn signal light.
Installation is in the reverse order of removal.
TORQUE: 0.9 N·m (0.1 kgf·m, 0.7 lbf·ft)
