12 - 2
1902/1912 Scanner Product Specifications
Humidity 0 to 95% non-condensing
Mechanical Drop
Operational after 50 drops from 6 feet
(1.83m) to concrete at 23°C
Vibration Withstands 5G peak from 22 to 300 Hz
ESD Tolerance
Up to 15kV direct air
Up to 8 kV indirect coupling plane
Parameter Specification
Dimensions (Typical):
Height
6.3 inches (16 cm)
Length
4.1 inches (10.41cm)
Width
2.8 inches (7.11cm)
Weight
7.5 ounces (212.62g)
Illumination LED:
Peak Wavelength
624nm +
18nm (red LED)
IEC 62471: “Exempt Risk Group”
442nm, 552nm (white LED)
IEC 62471: “Exempt Risk Group”
Aiming:
Peak Wavelength Laser
650nm
IEC 60825-1: “Class 2”
Peak Wavelength LED
624nm +
18nm
IEC 62471: “Exempt Risk Group”
Optical Power Laser
<1mW
Image Size 838 x 640 pixels
Skew Angle +
65°
Pitch Angle +
45°
Motion Tolerance:
Streaming Presentation Trigger up to 240 inches per second for 13 mil UPC
Symbol Contrast Grade 1.0 (20% or greater)
Battery:
Lithium Ion
1800 mAHr minimum
Number of Scans Up to 50,000 per charge
Expected Hours of Operation 14
Expected Charge Time 4.5 hours
Parameter Specification
