12 - 3
*Storage outside of this temperature range could be detrimental to battery life.
CCB01-010BT Charge Base Product
Specifications
Radio:
Frequency
2.4 to 2.5 GHz (ISM Band) Frequency Hopping
Bluetooth v.2.1
Range
33 ft. (10 m) typical
Data Rate
Up to 1 MBps
Temperature Ranges:
Operating
32° F to +122° F (0° C to 50° C)
Storage*
-40°F to +158°F (-40°C to 70°C)
Humidity Up to 95% non-condensing
Mechanical Drop
Operational after 50 drops from 6 feet
(1.8 m) to concrete
Vibration Withstands 5G peak from 22 to 300 Hz
ESD Sensitivity
Up to 15kV direct air
Up to 8 kV indirect coupling plane
Sealant Rating IP41
Parameter Specification
Dimensions (Typical):
Height
3.2 inches (8.128cm)
Length
5.19 inches (13.183cm)
Width
3.98 inches (10.109cm)
Weight
6.3 oz (179g)
Voltage: 4.5 to 5.5 volts
Current Draw:
Host Terminal Port
500mA
Aux Power Port
1A
Charge Time 5 hours
Radio:
Frequency
2.4 to 2.5 GHz (ISM Band) Frequency Hopping
Bluetooth v.2.1
Range
33 ft. (10 m) typical
Data Rate
Up to 1 MBps
Parameter Specification
