Remote Sen
sor Configuration (Optional)
Remote Sensor Conf
iguration (Optional)
Master Board
When con
necting to a
remote s
ensor
, use an 18 A
WG cab
le gauge,
with a maximum
length of 100 f
eet (30 m).
