Functional Tests
8500C/8500C+ System Maintenance Manual D-7
jj. Press START key.
kk. Verify that display indicates (example in Figure D-3):
1800+
2 RPM
0.8+
0.08 IPS
275+
10°
ll. Press STOP key.
mm. Repeat steps bb. through ll. for all channels in Table D-2.
D.5.2 8500 Balancer/Analyzer System Test Procedure with 8520CS (Using
High Temp Accelerometers and Photocells)
NOTE: Thes tests build successively on the first test in this section. Any settings not
mentioned must be left as they were in the previous test.
D.5.2.1 Test Setup
a. Connect equipment as shown if Figure D-4.
NOTE: Make sure calibrator Accelerometer cables are free to move so that Accelerometer
movement is not inhibited.
D.5.2.2 Power-Up Self-Test
b. Hold down START key on 8500C/C+ and turn on power supply.
NOTE: This erases all memory in 8500C/C+.
c. Wait until Power-Up Self-Test display appears and release START key.
D.5.2.3 Balance Test
d. Ensure that the only one piece of reflective tape is installed on the Calibrator 11A rotor
CAM.
e. Set CAM RATE (RPM) switch to 1800.
f. Set MOTOR switch to ON.
