5-2 Chadwick-Helmuth A Business Unit of Honeywell International, Inc.
Chapter 5 - Maintenance And Repair
Figure 5-1. Test Cable Fabrication Information
11A Calibrator Chadwick-Helmuth N/A
HP-3561A Spectrum
Analyzer
Hewlett-Packard Amplitude Accuracy
+/- 0.15 dB @ 1 kHz
(1.74%)
8278 Cable Chadwick-Helmuth BNC-to-Velocimeter
10502 Cable Chadwick-Helmuth BNC-to-Magnetic Pickup
N/A BNC T-
connector
Any
N/A Cable, coaxial
(2 ea)
Any BNC-to-BNC
10808-5 Cable Chadwick-Helmuth Magnetic pickup cable, 5 ft
5876
(Model 3030)
Magnetic
Pickup
Chadwick-Helmuth See appropriate
documentation
Table 5-1. Test Equipment
Part No. Nomenclature Manufacturer Characteristics
Test Cable #8278, Velocimeter-to-BNC
Test Cable #10502, Magnetic Pickup-to-BNC
B
D
A
B
D
C
NC
NC
SHIELD
SHIELD
Use any of these 6-pin connectors (or similar
connectors--crimped or soldered):
C-H #402-1061E (crimped pins)
MS3476L10-6P (crimped pins)
ITT Cannon #PV76L10-6P (crimped pins)
Use any of these 4-pin connectors (or similar connectors):
C-H #402-0841B (soldered pins)
MS3116F8-4P (soldered pins)
MS3126F8-4P (crimped pins)
ITT Cannon #KPSE06F8-4P (crimped pins)
ITT Cannon #KPT06F8-4P (soldered pins)
RG-58 Coax Cable
RG-58 Coax Cable
FILENAME: TESTCABL.DRW
Continued
To Next Page
