Functional Tests
8500C/8500C+ System Maintenance Manual D-9
p. Select PICKUP field with arrow keys.
q. Press CHANGE soft key to select PICKUP C.
r. Select INPUT field with arrow keys.
s. Key in 3 with numeric key.
t. Press ENTER soft key.
u. Wait 10 seconds.
v. Press START key.
w. Verify that final results display indicates.
1800 +
2 RPM
0.8 +
0.10 IPS
NOTE: This response assumes that internal charge converters have been properly
programmed for the sensors under test. (ref. Section D.6 for charge amplifier programming/
calibration).
x. Press STOP key.
y. Press SETUP key.
z. Select INPUT field with arrow keys.
aa. Key in 6 with numeric key.
bb. Press ENTER soft key.
cc. Wait 10 seconds.
dd. Press START key.
ee. Verify that final results display indicates.
1800 +
2 RPM
0.8 +
0.10 IPS
ff. Press STOP key.
gg. Move 10700 cables to High Temp Accelerometer 9 and 12 channel positions and move
cable 14883 to photocell channel D.
hh. Press SETUP on 8500C/C+.
ii. Select PICKUP field with arrow keys.
jj. Press CHANGE soft key to select pickup shown in Table D-3.
kk. Select INPUT field with arrow keys.
ll. Key in channel number 9 with numeric key.
mm. Press ENTER soft key.
nn. Wait 10 seconds.
