1-2
1. OVERVIEW
1.1 RECORDER OVERVIEW
1.1.1 INTRODUCTION
This recorder is a precision measuring instrument that offers many features.
• Up to 24 analog input channels,
• Compact size: 320 mm (12.60 '') depth, 310 mm front face height x 317 mm width (12.21 '' x 12.48 ''),
278 mm x 278 mm (10.95 '' x 10.95 '') cutout,
• 180 mm chart in either roll or fanfold presentation,
• Universal power supply: 100 to 240 V ac/dc,
• IP55 front panel protection,
• Universal input with a wide choice of actuation/range,
• Option linear input,
• High accuracy: 0.05 % via field calibration,
• Easy interactive product configuration,
• Large, clear operator display,
• Fast scanning rate:
2 channels = 105 ms
4 channels = 210 ms
8 channels = 420 ms
12 channels = 630 ms
16 channels = 840 ms
20 channels = 1050 ms
24 channels = 1260 ms
• Configurable alphanumeric chart documentation,
• Up to 48 alarm setpoints with a wide choice of alarm types,
• Event alarm: End of chart paper, sensor burnout, clock battery low, etc.,
• Up to 48 customer messages of 50 characters each,
• Standard chart illumination,
