9. PRODUCT SPECIFICATION SHEET
Technical data
Technology
Microprocessor-based (32 bits), with non-volatile memory. Flash memory for
product software upgrade or specials, via the front jack.
Analog inputs
Number of inputs
Input boards
Signal source
Basic mathematical
Functions
Filter
Field calibration
Burnout
Scanning time
Input impedance
Stray rejection
From 4 up to 24 in group of 4
2 types: 4 linear inputs per board: mV, V, mA
4 Universal inputs per board: mV, V, mA, T/C, RTD, Ohms
Thermocouple with cold junction compensation, or with remote compensation
temperature configurable between 0 to 80
o
C (32 to 176
o
F)
Line resistance up to 1000 ohms for T/C, mV, mA, V
RTD Pt 100 Ohms, 3-wire connections, 40
Ω balanced max.
Square Root extraction or channel differential are standard.
Digital filter configurable per input from 0 to 99 seconds.
Channel field calibration 0 to 100% span (or calibration of a group of identical
channels) can be made to certify input sensor loop.
T/C, mV, V (except following ranges) configurable to upscale, to downscale or
none.
Volt: -500, 0, 500 mV; -1, 0, 1 V; -2, 0, 2 V; -5, 0, 5 V; 0, 10 V; -10, 0, 10 V :
Inherent to zero
RTD: Inherent upscale.
mA: Inherent downscale
2 channels = 105 ms, 4 channels = 210 ms, 8 channels = 420 ms,
12 channels = 630 ms, 16 channels = 840 ms, 20 channels = 1 sec,
24 channels = 1.2 secs
10 Mohm for T/C, mV inputs, >1 Mohm for volt inputs.
Series mode > 60 dB. Common mode at 120 V AC > 130 dB.
Display
Fluorescent display
Brightness
2 rows of 16 digits, 8.5 mm (.33 inch) high, matrix display.
Can display 1 or 2 PV values (5 digits) per line, engineering units (5 digits), alarm
status, tag name, maths, speed, event messages etc.
The display brightness is configurable.
Record
Chart
Traces
Trace assignment
Scaling
180 mm (7.08 inch) width
Up to 24 traces, configurable in 6 colors, thin or thick traces, plus digital traces
Traces are configurable on analog inputs, maths, comm. or digital inputs
Per input, up to 2 analog scales are configurable and can be printed on the
chart with the engineering unit, channel reference and tag name.
Each input can be configured independently.
The scale can be linear, with up to 10 sub-divisions
