2-22
2. INSTALLATION
2.7 INSTALLING THE PRINTING SYSTEM
Before doing it, please remove the chart cassette from the chassis as indicated page 2-15.
The recorder automatically moves the print carriage to the correct position for the installation of the ink
ribbon cartridge by:
!
CAUTION
Do not attempt to install the ribbon cartridge while the chart cassette is in place.
Failure to comply with these instructions may result in product damage
