7-10
7. TROUBLESHOOTING
7.24 ERROR MESSAGES
NO TRACE
Display is selected for traces but no traces are configures in the chart configuration on each channel
NO PAPER
No paper in the cassette has activated the “Paper Out” switch or the cassette has been removed
END PAPER
The Chart Length counter has reached 0
BATTERY FAIL
The Lithium Battery for the Real Time Clock is at the level less than 3V
ONE ALARM ON
The configured Alarm/Event has occurred
BURNOUT
The input is configured and in a Burnout Condition or an input in burnout has disabled
SHEDTIME
The configured time period within which the communications response has not occurred
PRT INHIBIT
All print actions have been inhibited
OVERFLOW SPEED
The print buffer is near is capacity, filling the printer requirements with alarm messages and chart
documentation information. Buffer will fill if paper is not installed. Remove power and install chart paper.
EV PRECURSOR
Event precursor mode is enabled and the recorder is in standby
TEST PASSED
The recorder passes the self-test (diagnostic and running-in test)
TEST FAILED
The recorder fails the self-test (either diagnosis or running-in test)
NO RESPONSE
There is no communication between the recorder and the PCconfigurator
BAD CARRIAGE DISPLACEMENT
The carriage movement requires more steps to reach the “zero reference” than the processor expects
BAD REFERENCE
Zero reference sensor bad or not connected
