9-2
9. PRODUCT SPECIFICATION SHEET
Technical data
Print mode
Zoning
Printing group
Pen carriage speed
Trend: Up to 24 traces, with periodic chart documentation configurable in
time, from 1 minute to 24 hours with date, time, scales, digital PV print-out
over traces or on blank paper, with channel reference, digital traces, alarm
messages and customer message
Tabular: Tabular print-out configurable in time from 1 to 1440 minutes with
channel number, tag name, digital PV value, engineering unit, alarm status
Each input can be scaled between 0 to 100 % of the chart. (min. zone =
20%)
Up to 2 groups of channels can be defined, with printing selection by:
Alarm, logic inputs or triggers.
1.4 seconds full scale
Chart length
Roll and Fanfold chart 35 m (115 ft.)
Chart speed
Speed setting
Resolution
1 or 2 chart speeds, fully configurable, selected by: Logic input, alarm,
communication, front key
Speeds 1 and 2 are configurable from 1 (0.04) up to 5000 mm/hr (200
inch/hr)
Chart resolution is 0.19 mm (0.0075”)
Product configuration
Access
Protection
Front keys
PC configuration
The configuration can be accessed using front keys, PC Configurator
Communication.
2 password levels protect the unit configuration from unauthorized access.
Level 1 = limited access, Level 2 = full protection
Configurable and alphanumeric keys allow the operator to change the recorder
operation.
Through the front jack the unit can be configured from a PC through a PC interface.
This provides the facility to copy the configuration, modify, store, download or
upload the configuration, access service diagnostics, and also to upgrade the
recorder firmware.
Logic inputs (optional)
Number of inputs
Actions
Up to 36 input contacts, organized in groups of 6 contacts per card
Dry contacts (5 mA - 5 V dc)
Change chart speed 1 to speed 2, tab interval 1 to tab interval 2, digital
print-out, print message, print inhibit, event traces, print math calculations.
Change range, start/stop math operations.
Change print group, actuate a relay output.
Up to 36 event traces are configurable in color and position from 0 to 100% of the
chart.
Alarms
Setpoints
Alarm type
Up to 48 alarm setpoints, freely assignable to analog inputs, maths or comm.
High, low, change rate high, change rate low, change rate high-low or deviation
with configurable alarm occurrence
