1. OVERVIEW
1.2 MODEL SELECTION GUIDE
This table helps you to identify correctly the unit in front of you. Please refer to the product label and verify
that you have the right unit.
Instructions
Refer to Supplementary Ordering Data before order entry.
Select the desired Key Number. The arrow to the right marks the selection available.
Make selections from Tables I through VII using the column below the proper arrow. A
dot ( ) denotes unrestricted availability. A letter denotes restricted availability.
A complete Model Number must have the designated number of digits in each table.
Ke
y
Number
I II III IV
D18
- _ _ _ _ _ _ - _ _ _ _ _ _ - _ _ _ _ - _ -
V
V
I
V
II
_
_
_
_
-
_
_
-
_
KEY NUMBER Selection Availability
Description
DPR 180 Stri
p
Chart Recorder D18
TABLE I - Analo
g
In
p
uts
(
Note 1
)
Input Card 1 None 0 _ _ _ _ _
(Slot A) 4 Linear Inputs (Channel 1 to 4) L _ _ _ _ _
4 Universal Inputs (Channel 1 to 4) U _ _ _ _ _
Input Card 2 None _ 0 _ _ _ _
(Slot B) 4 Linear Inputs (Channel 5 to 8) _ L _ _ _ _
4 Universal Inputs (Channel 5 to 8) _ U _ _ _ _
Input Card 3 None _ _ 0 _ _ _
(Slot C) 4 Linear Inputs (Channel 9 to 12) _ _ L _ _ _
4 Universal In
p
uts
(
Channel 9 to 12
)
_ _ U _ _ _
Input Card 4 None _ _ _ 0 _ _
(Slot D) 4 Linear Inputs (Channel 13 to 16) _ _ _ L _ _
4 Universal Inputs (Channel 13 to 16) _ _ _ U _ _
Input Card 5 None _ _ _ _ 0 _
(Slot E) 4 Linear Inputs (Channel 17 to 20) _ _ _ _ L _
4 Universal Inputs (Channel 17 to 20) _ _ _ _ U _
Input Card 6 None _ _ _ _ _ 0
(Slot F) 4 Linear Inputs (Channel 21 to 24) _ _ _ _ _ L
4 Universal Inputs (Channel 21 to 24) _ _ _ _ _ U
