9. PRODUCT SPECIFICATION SHEET
Technical data
PCMCIA (optional)
PCMCIA cards
Actions
PC analysis
PCMCIA memory cards are ATA type II compatible and use flash technology for
longer data retention.
Memory size starts from 2 Mb up to 75 Mb
Archiving of PV traces, alarms and events with file names. Logging time
selectable from 1 second up to 30 minutes.
The TrendManager Pro software provides an easy and powerful way to analyze
trend, alarm and event files as well as to export them in spreadsheet format.
(CSV)
Retransmitting signals (optional)
Current output
Up to 8 signals, 4 to 20 mA dc, can be generated by the recorder (organized in
blocks of 4 output signals).
Max. Line impedance = 400 Ohms
These can be configured for: analog traces, math calculations, PV's from the
communication link.
The zero and span are configurable.
Factory accuracy: 0.15%
Field calibration accuracy: 0.05%
Temperature drift: 75 ppm
Clock timer
Format
Power interruption
Accuracy
Year, month, hour, minute can be set
Battery backed (10 years time, 3 years power off)
10-
5
at reference conditions.
Power supply
100 to 240 V ac/dc (24 V ac/dc on special request)
Power consumption = 100 VA max.
Packaging
Weight
Front bezel
Panel cutout
Depth
Front protection
Lock
Door
Mounting
Wiring
18 kg max. (38 lbs)
310 x 317 mm (12.2 x 12.5 inches)
278 x 278 mm (10.9 x 10.9 inches)
320 mm (12.6 inches) including the rear cover
IP 55
Latch, optional key (DIN 43832-N)
Die cast aluminum: Dark gray or black (optional), door opens to 180°
Panel mounting ±30° from the horizontal
Screw terminals: Terminal blocks plug on to the boards at the back of the
recorder.
Noise immunity/Isolation
This product is in conformity with the protection requirem ents of the follow ing
European Council Directives:
73/23/EEC, the Low Voltage Dir ective and 89/336/EEC, the EMC
Directive. Conformity of this product with any other “CE Mark” Directive(s)
shall not be assumed.
EMC Classification: EN61326-1 Electromagnetic Compatibility – General
Emission Standard, Part 2: Industrial Environment.
EN61326-1 Electromagnetic Compatibility – General Immunity Standard, Part
2:Industrial Environment.
Safety protection
Complies with EN61010-1 and UL 3121 for process control
instrumentation. Pollution Degree 2. Installation Category II
