Installation SmartRadar FlexLine
Installation Guide Part No.: 4417.760_Rev06
24
4.8 Preparations for Installation without SmartConn
4.8.1 Remove Top Cover
FIG. 4-4 Removing the top cover
Open display cover (A)
Move up top cover (B) at the front
Remove top cover
B
A
