4.10.3 Unused Cable Inlets
 Seal unused cable inlets with approved 3/4” threaded
stopping plugs.
4.11 Electrical Connection
CAUTION!
Cables must always comply with the defined cable
specifications.
CAUTION!
• Minimum incoming wire cross section should be at least
0.2 mm
2
and may consist of a single-, fine- or multi-
wire. With the use of wire with a cross section between
≥0.2 mm
2
and <0.5 mm
2
, the maximum current I [A]
should be reduced to a maximum of I = 0.55 A.
• With a minimum wire cross section of ≥0.5 mm
2
the
maximum current I should not be higher than 3 A and
may consist of a single-, fine- or multi-wire.
NOTE:
The field cabling entering the SmartConn box must be as
short as possible.
NOTE:
Depending on the ambient temperature classification the
cables must be suitable for Ta > 70°C.
