Product Description SmartRadar FlexLine
Part No.: 4417.760_Rev06 Installation Guide
13
3 PRODUCT DESCRIPTION
3.1 SmartRadar System Components
FIG. 3-1 System components
The device has following system components (see figure above):
Description
A SmartRadar FlexLine with separator coupling to radar antenna
B SmartView (optional)
C SmartConn (optional)
D Antenna connection (see antenna installation guide)
A
B
D
C
