Oxygen measuring device MySign
®
O
6 Doc no.: 065-07-1001825_MySignO_GB-0.pdf / 12.11
2 Designated use and description
Area of application
The oxygen measuring device MySign
®
O is designed to determine and monitor inspired
oxygen concentrations in breathing gas.
MySign
®
O can be used for monitoring the breathing gases dispensed by the following
devices:
x Anaesthesia breathing systems
x Respiratory equipment
x Infant incubators
x Oxygen therapy systems
The system is suitable for use inside hospitals as well as during transport (except by air),
emergencies and artificial respiration provided at home.
MySign
®
O must only be used with the EnviteC oxygen sensor, type OOM111
(Part No.: 01-00-0114), which is extremely reliable and stable and has been especially
adapted for use with the MySign monitor.
User profile
The oxygen monitor must be used only be correspondingly trained specialist medical hospital
staff (or relevant clinical staff). This system comes with the latest technologies for avoiding
incorrect measurements and for guaranteeing the highest possible level of measuring
accuracy. As a consequence, it constantly monitors the following functions and components.
x Signal transmitter x Oxygen sensor
x LED x Internal memory
x Battery
The system comes with a data memory module and a USB port. The data can be transferred
to a computer with the software “PC Software MySign
®
” and a data cable and analysed.
For more information, please see the section “PC software” in this manual and
the topic “PC software MySign
®
” in the online help.
Symbols on the label
Follow the instructions given in
the operating manual!
SN
Serial number
Date of manufacture
The system is a BF type system and
is susceptible to damage from
defibrillators.
PN
Product number
Follow the disposal instructions!
Manufacturer
IP
Protection class (DIN EN 60529)
