Periphery components for ESSER FACP
14 TI 798960.GB0 / 04.20
Part No. Detector type
Specific detector specifications
*3
802371
*2
Optical smoke detector
Quiescent current @ 19 V DC : 50 µA
Quiescent current @ FACP
battery
: 0.20 mA @ 27.5 V/0.28 mA @ 42 V
Usage temperature : -20 °C ... +72 °C
Specification : EN 54-7 /-17:2005
VdS approval : G 204060
Declaration of Performance : DoP-20104130701
802373
*2
OT multisensor
detector
Operating voltage : 9 V DC ... 42 V DC
Quiescent current @ 19 V DC : 50 µA
Quiescent current @ FACP
battery
: 0.20 mA @ 27.5 V/0.28 mA @ 42 V
Usage temperature : -20 °C ... +50 °C
Specification : EN 54-7 / -5 A2, CEA 4021
VdS approval : G 205070
Declaration of Performance : DoP-20111130701
802374
*2
O
2
T multisensor
detector
Quiescent current @ 19 V DC : 60 µA
Quiescent current @ FACP
battery
: 0.23 mA @ 27.5 V/0.33 mA @ 42 V
Usage temperature : -20 °C ... +65 °C
Specification : EN 54-7 / -5 B /-17:2005, CEA 4021
VdS approval : G 204061
Declaration of Performance : DoP-20105130701
802375
*2
OT
blue
multisensor
detector
Operating voltage : 9 V DC ... 42 V DC
Quiescent current @ 19 V DC : 50 µA
Quiescent current @ FACP
battery
: 0.20 mA @ 27.5 V/0.28 mA @ 42 V
Usage temperature : -20 °C ... +50 °C
Specification : EN 54-7 / -5 A2 /-17:2005, CEA 4021
VdS approval : G 205071
Declaration of Performance : DoP-20113130701
802379
*2
OT
blue
LKM multisensor
detector
Operating voltage : 9 V DC ... 42 V DC
Quiescent current @ 19 V DC : 50 µA
Quiescent current @ FACP
battery
: 0.20 mA @ 27.5 V/0.28 mA @ 42 V
Air speed : 1 … 20 m/s
Usage temperature : -20 °C ... +50 °C
Specification : EN 54-17:2005, CEA 4021
VdS approval : G 207128
Declaration of Performance : DoP-20113130701
802473
*2
OTG multisensor
detector
Quiescent current @ 19 V DC : 65 µA
Quiescent current @ FACP
battery
: 0.25 mA @ 27.5 V/0.36 mA @ 42 V
Monitoring area : max. 110 m²
Monitoring height : max. 12 m
CO pre-alarm : approx. 75 ppm
CO alarm : approx. 100 ppm
Usage temperature : -20 °C ... +50 °C
Specification : EN 54-7 /-5 A2 /-17:2005, CEA 4021
VdS approval : G 205072
Declaration of Performance : DoP-20115130701
*1
Heat sensor type
*2
Smoke sensor type
*3
The information applies for the entire series incl. .MAR, .N0, .NU etc.
