Periphery components for ESSER FACP
28 TI 798960.GB0 / 04.20
IP 43 damp location base adapter surface-mounting (Part No. 805572.50)
The damp room socket adapter was designed specifically for the surface
mounted cable feed through cable protection pipes and has three
breakthrough inputs for M20 cable glands (optional).
Fig. 11: IP 43 damp location base adapter surface-mounting
46
Art.-Nr. / Part No. 805572.50
Option
8
16 / 4
Fig. 12: Installation
IP 42 protection (Part No. 805570) and IP 43 protection (Part No. 805573)
For installation in environments with dust and
humidity. IP protection prevents dust and moisture
entering the detector base.
Fig. 13: IP Protection
