Honeywell ESSER FACP User Manual

Periphery components for ESSER FACP
TI 798960.GB0 / 04.20 41
Detector Specifications (not ATEX)
Standard MCP Ex (i)
804920.EX
IQ8MCP Ex (i)
804924.EX
Operating voltage
:
8 V DC … 30 V DC
8 V DC … 42 V DC
Contact rating S2
:
max. 30 V DC / 1 A
---
Quiescent current
:
---
approx. 45 µA @ 19 V DC
Alarm current
:
approx. 9 mA @ 9 V DC
approx. 9 mA @ 19 V DC, pulsed
Operating indicator
:
---
LED, green
Alarm indicator
:
LED, red
LED, red
Terminals
:
max. 2,5 mm² (AWG 26-14)
Ambient temperature
:
-20 °C … +70 °C
Storage temperature
:
-30 °C … +75 °C
Protection rating
:
IP 44
Housing
:
PC ASA plastic
Weight
:
approx. 236 g (in housing)
Dimensions housing (w x h x
d)
:
133 x 133 x 36 (mm)
Specification
:
EN 54-11 : 2001 + A1:2005, type B
VdS approval
:
G 214113
G 214114
Declaration of performance
:
DoP‐21417141219
DoP-21418141219
Standard MCP Ex (i)
804960.EX
IQ8MCP Ex (i)
804961.EX
Operating voltage
:
8 V DC … 30 V DC
8 V DC … 42 V DC
Quiescent current
:
---
approx. 45 μA @ 19 V DC
Alarm current
:
approx. 9 mA @ 9 V DC
approx. 9 mA @ 19 V DC, pulsed
Operating indicator
:
---
green LED
Alarm indicator
:
red LED and yellow flag
Terminals
:
max. 1,5 mm² (AWG 30-14)
Ambient temperature
:
-20 °C … +70 °C
Storage temperature
:
-30 °C … +75 °C
Protection rating
:
IP 66 / 67
Housing
:
PC ASA plastic
Colour
:
red (similar to RAL 3020)
Weight
:
approx. 255 g
Dimensions housing (w x h x
d)
:
88 x 88 x 21 (mm)
Dimensions incl.
mounting housing
:
88 x 88 x 57 (mm)
Specification
:
EN 54-11:2001 + A1:2005, Typ A
VdS approval
:
G 214115
G 214116
Declaration of performance
:
DoP‐21415141219
DoP‐21416141219
For further information, safety calculations and certifications, see Technical Information 798920.EU.xx.
