Periphery components for ESSER FACP
42 TI 798960.GB0 / 04.20
6.6.2 Addressable MCP, IP66
Addressable manual call point in conformity with EN 54-11 type B with loop isolator (Part No. 761694) for use
on esserbus
®
/ esserbus
®
Plus for manually triggering fire alarms or hazard alarms. For outdoor application or
application in damp environments.
Fig. 29: Addressable MCP, IP66
Specifications
Operating voltage : 8 ... 42 V DC
Quiescent current : approx. 45 μA @ 19 V DC
No. of detector / zone : max. 10 (according to VdS), 127 / loop
Alarm display : LED red
Connection terminal : max. 1.5 mm²
Application temperature : -20 °C ... 70 °C
Storage temperature : -25 °C ... 75 °C
Type of protection : IP 66
Housing : PC-plastic
Color : red, similar to RAL 3000
Weight : approx. 700 g
Dimensions : 135 x 135 x 61 (mm)
Declaration of Performance : DoP-20882130701
For further information refer to product catalogue.
