74 ES-50X Series Manual — P/N LS10129-000FL-E:E 5/23/2022
Programming Master Programming Level
Pressing 1 while viewing the Banner Screen will select the blank factory default banner setting and display the
following screen:
Pressing the Enter key will store this selection in nonvolatile memory and return the display to the Banner Screen.
Pressing 2 while viewing the Banner Screen will cause the following screens to be displayed:
These screens allow the programmer to enter a two line custom banner. A flashing cursor will appear in the bottom left corner of each dis-
play. A maximum of 20 characters (including spaces) can be entered into each screen for a total of two lines with 40 characters. After enter-
ing up to 20 characters in the first screen, press Enter to view the second screen. Enter up to 20 characters in the second screen in the same
manner or just press Enter if a second banner line is not being entered. To quickly clear the current banner, press the CLR key.
To enter alphanumeric characters from the keypad, repeatedly press the appropriate key until the desired character is displayed in the first
position. For example, to enter the letter B, press the 2 (ABC) key three times to toggle through the characters 1, A, and B. Press the right
arrow key to move the cursor one position to the right and repeat the process to enter the next character. To enter a space, press the 9 (YZ) key
four times to place a blank in the desired position. When all characters have been entered, press the Enter key to store the information. The
display will return to the Banner Screen.
Time-Date
The control panel time and date can be changed by pressing 3 while viewing the System Setup Screen #1. The
following screen will be displayed:
Time
To change the time, press 1 while viewing the Time-Date Screen. The following screen will be displayed:
A flashing cursor is located toward the top left of the display. Below the cursor is the current time. To change the time, enter the two-digit
hours followed by the two-digit minutes. The cursor will move one position to the right each time a digit is entered. After the last minutes
digit is entered, the cursor will again move one position to the right. At this point enter 1 for AM or 2 for PM. The display will then return to
the Time-Date Screen which will show the new time entry. If an error is made while entering a digit, press the CLR key to delete the entire
entry and beginning again.
Date
To change the date, press 2 while viewing the Time-Date Screen. The following screen will be displayed:
A flashing cursor is located toward the top left of the display. Below the cursor is the current date. To change the date, enter the two-digit
month followed by the two-digit day and then the two-digit year (17 for 2017, 18 for 2018, etc.). The cursor will move one position to the
right each time a digit is entered. After the last year digit is entered, the display will return to the Time-Date Screen which will show the new
date entry. If an error is made while entering a digit, press the CLR key to delete the entire entry and beginning again.
BANNER
1=FACTORY
2=USER DEFINED
Banner Screen
FACTORY BANNER
Factory Banner Screen
USER DEFINED BANNER
PRESS ENTER IF OK
User Defined Banner Screen #1
USER BANNER - LINE 2
PRESS ENTER IF OK
44444444444444444444
User Defined Banner Screen #2
SYSTEM SETUP
1=TROUBLE REM
2=BANNER
3=TIME-DATE
System Setup Screen #1
TIME AND DATE
1=TIME 10:00 AM
2=DATE 05-04-2017
3=CLOCK FORMAT 12HR
Time-Date Screen #1
TIME AND DATE
1=DAYLIGHT SAVINGS
Time-Date Screen #2
ENTER TIME
10:00 AM
1=AM 2=PM
Time Screen
ENTER DATE
MONTH DAY YEAR
05-04-17
Date Screen
