82 ES-50X Series Manual — P/N LS10129-000FL-E:E 5/23/2022
Programming Master Programming Level
In addition, the aux power output can be programmed as resettable or non-resettable power. Non-resettable power is suitable for powering
annunciators while resettable power is suitable for powering smoke detectors. Each press of the 1 key will cause the display to toggle
between Resettable Yes and Resettable No.
Trouble Reminder
The Trouble Reminder features causes the control panel piezo to sound a reminder ‘beep’ for alarms and trou-
bles, after the panel has been silenced. Refer to “Trouble Reminder” on page 72, for a detailed description of
this feature. Pressing 2 while viewing System Setup Screen #4 will cause the display to toggle to Trouble Rem
4 or Trouble Rem 24, which enables this feature for resound at either 4 or 24 hours, respectively. Each press of
the 2 key will cause the display to toggle between Trouble Rem 4 or Trouble Rem 24. Refer to the table on
page 48 for permissible settings.
Language
The language option is used to change the text on the panel display to either English or French. Pressing the 3
key will cause the display to offer a choice of 1=English and 2=French.
Charger Enable
If using an external battery charger, the FACP battery charger must first be disabled. Pressing 1 while viewing
System Setup Screen #5 will cause the display to toggle to Charger Enab No, which will allow the use of an
external battery charger. Each press of the 1 key will cause the display to toggle between Charger Enab. No and
Charger Enab. Yes.
4XTMF Supervision
If a 4XTMF Transmitter Module is installed in the system, supervision must enabled in user programming.
Pressing 2 while viewing System Setup Screen #5 will cause the display to toggle to 4XTM Supv Enab. Yes,
which means there is a 4XTMF installed. Each press of the 2 key will cause the display to toggle between
4XTM Supv Enab. No and 4XTM Supv Enab. Yes. Refer to the table on page 48 for permissible settings.
Remote Sync Enable
Synchronization is a feature that controls the activation of notification appliances in such a way that all devices
will turn on and off at exactly the same time. Refer to Section 2.5, “Remote Synchronization Output”, on page
28 for more information. To enable remote synchronization, press the 3 key while viewing System Setup
Screen #5. Each press of the key will toggle the screen between Rem Sync Enab Yes and Rem Sync Enab No.
3.5.6 History
The History option allows an authorized user to view or erase events which have occurred in the control panel.
Pressing 1 while viewing Programming Screen #3 will display the History options as shown in the following
display:
View Events
Pressing 1 while viewing the History Screen will allow the user to select the events to be viewed as illustrated in
the following:
While displaying the View Events screen, press 1 to view all events, 2 to view only alarms or 3 to view other events. Use the up and down
arrow keys to scroll through all of the displayed events.
SYSTEM SETUP
1=AUX POWER
2=TROUBLE REM 24HR
3=LANGUAGE ENGLISH
System Setup Screen #4
SYSTEM SETUP
1=AUX POWER
2=TROUBLE REM 24HR
3=LANGUAGE ENGLISH
System Setup Screen #4
SYSTEM SETUP
1=CHARGER ENAB YES
2=4XTM SPV ENAB NO
3=REM SYNC ENAB YES
System Setup Screen #5
SYSTEM SETUP
1=CHARGER ENAB YES
2=4XTM SPV ENAB NO
3=REM SYNC ENAB YES
System Setup Screen #5
SYSTEM SETUP
1=CHARGER ENAB YES
2=4XTM SUPV ENAB NO
3=REM SYNC ENAB YES
System Setup Screen #5
PROGRAMMING
1=HISTORY
2=COMMUNICATOR
3=ANNUNCIATORS
Programming Screen #3
HISTORY
1=VIEW EVENTS
2=ERASE HISTORY
History Screen
HISTORY
1=VIEW EVENTS
2=ERASE HISTORY
History Screen
HISTORY
1=VIEW ALL
2=VIEW ALARMS
3=VIEW OTHER EVENTS
View Events Screen
