Galaxy 3 Series Programming Manual
103
54 - Links (cont’d)
Table 24. Link destination
NOTE: ¹¹There are 16 Link timers in the system. These Link timers are triggered by the Latch and Reflex
timer destinations. Both the Latch and Reflex options operate the same set of Link timers. They just
start the timers in different ways. A Latch timer can restart the Link timer while it is running. A Reflex
timer cannot.
Destination Type
* Modifier
Notes
a) Not used - The link is not operational.
b) Zone Address -
When the link is active, the zone is omitted from
the system
c) User Code -
When the link is active, the user's PIN and MAX
card are not operational.
d) Output Type -
When the link is active, all outputs programmed
with the selected function are activated.
e) Output Address -
When the link is active, the specific output
address is switched on. Please note that when
using the output address as the destination, the
deactivation of the link will switch the output off
immediately, overriding any pulse time or latch
mode of the output programming.
f) Keypad Address -
When the link is active, the buttons on the keypad
will not operate.
g) MAX Address Off
When the link is active, the MAX reader will not
read cards.
On
When the link is active, the door lock relay for the
reader will constantly be in the unlocked state.
The door contact input will also be bypassed so
that no alarm will occur.
h) Latch Timer** -
When the link is deactivated, the Link Timer
starts to count down from the Latch timer value.
Each subsequent activation of the link will restart
the timer count down to this value. When the
timer reaches zero the Link timer activates and it
can trigger another link. If the link is continuously
activated within the timer period, the counter will
never reach zero and the Link timer will be held
off. The application for this would be a link that
didn't activate so long as another event continues
to happen with the time period.
i) Reflex Timer** -
The Reflex timers operate identically to the Latch
timer except that the timer cannot be restarted
while it is running. A Reflex timer destination will
still start a Link Timer running in the same way as
a Latch timer destination.
An application for this would be a delayed action
link.
