Options [63] Galaxy Flex Installer Manual
170
Group Name Display
When viewing the groups assigned to an option, for example user code or outputs, you can
press # and
together to display the groups individually. The keypad displays the group
number, name and the status of the particular option being displayed.
Press # to toggle the status of the group. To move to another group, press A or B, or enter
the number of the group directly.
Notes on Groups
1. All zones default to group 1.
2. All keypads, user codes and outputs default to all system groups assigned.
3. Remove unused groups from user codes, otherwise the unused groups will set and unset
even though they are not programmed.
4. Final, Keyswitch and Exit can be programmed to function with regard to other groups
during the setting and unsetting procedures (refer to option Program Zones [52]).
5. Outputs can be assigned to any selection of groups. Output activation can be made
dependent on the set or unset status of the assigned groups (refer to Program Outputs
[53]).
6. After programming zones, codes, keypads and outputs into their various groups they
remain programmed if the Group Mode function is disabled. Only Group 1 remains
active.
7. The control panel has multi-user software that allows several users to operate the
system simultaneously.
A2 Sales Dept S
[<],[>],#=CHANGE
current group name
selected group
press A or B to
move to another
group
group status
press # to toggle status
