Honeywell IQ8Control C User Manual

Fire Alarm Control Panel IQ8Control C/M
110 FB 798951.GB0 / 01.09
Checking the essernet
®
devices and connections
An additional check of the essernet
®
devices/connections can be carried out using the essernet
®
micro modules
(from index “E” onwards).
Switching on the display on the fire alarm control panel:
Press key
F3
Test
6
Test
The displays are switched off using the key switch.
Display Value
(example)
Meaning
1555
Number of telegrams received without error at terminals 1+2 of the
essernet
®
micro module.
Automatic update of the values:
Direction 12
essernet
®
micro module 62.5 kBd: every 45 seconds
essernet
®
micro module 500 kBd: every 10 seconds
Direction 34 1551 Terminals 3+4 (see “Direction 12”)
Fault 12 [%] 0
Percentage display of the faulty telegrams which are received at
terminals 1+2 of the essernet
®
micro module. Automatic update of the
values:
essernet
®
micro module 62.5 kBd: every 45 seconds
essernet
®
micro module 500 kBd: every 10 seconds
Fault 34 [%] 0 Terminals 3+4 (see “Fault 12”)
Fault. Max 12 [%] 6
Maximum percentage value of the faulty telegrams received at terminals
1+2 since the panel was last restarted. This function enables a
measurement over a longer period and is reset to “0” after every restart
of the FACP.
Fault. Max 34 [%] 8 Terminals 3+4 (see “Fault. Max 12”)
Repeat telegram 4 Number of repetition requests.
Repetition requests for telegrams are a sign that there are faults on a
module or on the transmission path.
Panel no. 10
Display of the micro module address which has been set on the
essernet
®
module. This address must correspond to the customer data
of the FACP.
The counters are reset when the FACP is restarted.
