Honeywell IQ8Control C User Manual

Fire Alarm Control Panel IQ8Control C/M
FB 798951.GB0 / 01.09 67
5.1.2.1 esserbus
®
PLus alarm devices
Available loop alarm devices for directly connection to the esserbus
®
PLus analog loop.
Part No. Name Load factor (LF)
Fire detector IQ8Quad
802383
Visual
802384 Audible
2
802385, 802385.SVxx Visual + audible + speech
3
802386, 802386.SVxx Audible + speech
Alarm device IQ8Alarm
807205, 807206
Audible
807212, 807213, 807214,
Visual
Î sphere colour red or amber
white, blue or green
807224
3
Audible + speech
807322, 807332
Audible + visual
807372, 807372.SVxx
Audible + visual + speech
Base sounder
806282 Audible
2
esserbus
®
PLus loop length Max. total load factor

700 m
96
1000 m 78
1300 m 66
1600 m 54
2000 m 48
2500 m 42
3000 m 36
3500 m (max. loop length) 30
Example:
The following alarm devices are connected to a loop:
8 Fire detector IQ8Quad
(Part No. 802385) with load factor 3
9 alarm devices IQ8Alarm with load factor 3
Total load factor
= Load factor 24
+
= Load factor 27
______________
= 51
Result: The total load factor obtained in this example allows for a loop length of max.1600 m (refer table).

observe max. permitted loop length
1)
 check compatibility of loop devices
 do not exceed the max. admissible total load factor of 96 (per loop)
 observe max. number of alarm devices on the loop for each individual device type
 max. total number of 127 loop devices per loop
1)
refer table chapter 5.1.3.
