Honeywell miniMAX User Manual

Rev. 1.0 4 900.0688
9-Dec-05
2.1 SETTING UP, CONTINUED
DIP Switch Settings on Controller Card HMX128 (left most board inside chassis)
1 2 3 4 5 6 7 8 Protocol
OFF OFF OFF OFF OFF OFF OFF OFF Honeywell series FastScan/SmartScan
ON OFF OFF OFF OFF OFF OFF OFF Honeywell series) KD6/HD6
OFF ON OFF OFF OFF OFF OFF OFF Maxpro RS-485
ON ON OFF OFF OFF OFF OFF OFF Maxpro AF-485
OFF OFF ON OFF OFF OFF OFF OFF Panasonic
ON OFF ON OFF OFF OFF OFF OFF Pelco AD Format
OFF ON ON OFF OFF OFF OFF OFF Vicon Std
ON ON ON OFF OFF OFF OFF OFF Vicon Extended
OFF OFF OFF ON OFF OFF OFF OFF Star Micronics
ON OFF OFF ON OFF OFF OFF OFF Videv
OFF ON OFF ON OFF OFF OFF OFF VCL
ON ON OFF ON OFF OFF OFF OFF Pelco P Format
OFF OFF ON ON OFF OFF OFF OFF JVC
ON OFF ON ON OFF OFF OFF OFF Speeddome
OFF ON ON ON OFF OFF OFF OFF Kalatel
ON ON ON ON OFF OFF OFF OFF Baxall 7000 Series
OFF OFF OFF OFF ON OFF OFF OFF Panasonic 850 Series 19K2 Baud
ON OFF OFF OFF ON OFF OFF OFF Panasonic 850 Series 9600 Baud
OFF ON OFF OFF ON OFF OFF OFF Forward Vision MIC1-300
1
ON ON OFF OFF ON OFF OFF OFF Pelco Coaxitron Interface Format
*
OFF OFF ON OFF ON OFF OFF OFF VST
2
3. Replace the front covers with the packing cardboard in place.
Do not
remove the cardboard at this time.
1
Available in MX308 firmware version 2.02 and MX128 board MS001284 and above.
2
Available in MX308 firmware version 2.06 and higher and MX128 board MS001284 and above.
