8.2 HARDWARE MAPPING, CONTINUED
b. Pan/tilt Control Ports
Physical Outputs on
HMX128 Control Card
Slot
(CSL field in SETMAX)
1 1
2 2
3 3
4 4
5 5
6 6
7 7
8 8
c. Text - The text is predefined in SETMAX.
Text
Slot
(TSL field in SETMAX)
Output Card 1 1-8
Output Card 2 9-16
Output Card 3 17-24
Output Card 4 25-32
d. Alarm Inputs - The alarm inputs only apply if the HMX4248 I/O Card is installed on
the rear of the switcher.
Alarm Input
Slot
(ASL field in SETMAX)
1-8 15
9-16 16
17-24 17
e. Contact Outputs - The contact outputs only apply if the HMX4248 I/O Card is
installed on the rear of the switcher.
Output #
Slot
(OSL field in SETMAX)
1-8 1
