6
Electrical
Voltage Supply: 2.5A @ +5V / 0.8A @ +12V
Operating: 11.9 Watts
Power:
Standby: 3.25 Watts
Operating: 1.7A @ 5.2V / 0.2A @ 12V
Current:
Standby: 0.6A @ 5.2V / 0.07A @ 12V
Current Limits on
Integrated Scale and/or
Scale Display:
Do not exceed maximum current of 12V @ 0.7A / 5V @ 0.2A
DC Transformers: Class I; 5.2VDC @ 2.5A; 12VDC @ 0.8A
For Regulatory Compliance Information, refer to pages 55 - 57.
Environmental
Operating Temperature: 0°C to 40°C (32°F to 104°F)
IP Rating: IP 55
Light Levels: 4842 Lux (450 footcandles)
Storage Temperature: -40°C to 60°C (-40°F to 140°F)
Humidity: 5% to 95% Relative Humidity, Non-Condensing
Contaminants: Sealed to resist airborne particulate contaminants.
Ventilation: None Required
Specifications are subject to change without notice.
