AM_8200 Programming Manual PAGE - 37
AM82000_manu-prog-ENG Doc. M-162.1-AM8200-ENG Rev A2 NOTIFIER ITALIA
INPUT MODULES FOR GENERAL SERVICES
CONNECTION TYPE SW Type_ID TYPE OF DEVICE
MTRB
Input Module used as a Tamper signaling. Through an alarm input it
signals a breakdown
MACK Input module used to perform remote ACK (pulse)
MTAC Input module used to perform remote SILENCING (pulse)
MRES Input module used to perform remote RESET (pulse)
OUTPUT MODULES
CONNECTION TYPE
SW Type_ID
TYPE OF DEVICE
FORC
Relay output module with potential free contacts.
CON
Output module with supervision of the line of command devices.
CONV
Output module with supervision of the line of controlled devices
(VdS standard compliant).
GSND
Software type dedicated to the following HW types (sirens
addressed): WMSS, WMS, WMS, DBSS, DBS
GSTR
Software Type dedicated to the following HW types (Directional
Flashes): WMSS, WMSB,, DBSS
