PAGE - 64 Programming Manual AM_8200
NOTIFIER ITALIA Doc. M-162.1-AM8200-ENG Rev A2 AM8200_manu-prog-ENG
Operators used in the control by event equation:
OR
is the operator which requires AT LEAST ONE operator to be ACTIVE.
Example: the output module equation is: OR (G9 G15 G23) or the OR operator can be omitted by entering:
(G9 G15 G23)
If ANY of the three operands in this equation (G9 G15 G23) is in alarm; the output module will be activated, that
is:
- IF the software group 9 is in alarm, or
- IF the software group 15 is in alarm, or
- IF the software group 23 is in alarm
- THEN this output module will be activated.
AND
is the operator which requires EACH operand to be ACTIVE.
Example: the output module equation is: AND (G9 G15 G23).
Only if ALL THREE operands in this equation are in alarm, the output module will be activated, that is
- IF the software group 9 is in alarm, or
- IF the software group 15 is in alarm, or
- IF the software group 23 is in alarm
- THEN this output module will be activated.
NOT
is the operator which DENIES the operand or the series of operands in brackets, which follow it.
Example: the equation of an output module is: NOT (G23).
The output module will remain activated until the operand (G23) IS alarmed, that is:
- If the software group 23 is in alarm
- THEN this output module will be deactivated.
N.B.
It is not allowed to write a CBE for a direct group, if the operands contained inside the round brackets
are some groups having an index lower than the group for which the CBE must be associated as in the
following example:
CBE not allowed
CBE allowed
G33 = (G23 G24)
G21 = (G23 G24)
