ID2000 Series Operating Manual
Operator Actions at Panel
32997-434-000-4, Issue 4
May 2010
9 To return to the ‘standard’ display, press
(on VDU
press ctrl/X). Alternatively, you may continue to use
the up and down arrows to examine other devices’
data.
The following facilities are also available:
a. LED pulsing option:
i The LED pulsing option is only available from the
panel keypad. It assists in identifying a sensor in
the field. Press
during continuous data display
of the appropriate sensor. The question shown
below is displayed:
ii Press
and the LEDs of that device will pulse
in a 1 second ON/1 second OFF mode. See
below for explanation of the DATA LOG question
which is next asked.
iii If the LEDs of this device were already pulsing,
you may stop this by repeating the above
procedure; in this case the question shown below
is asked. Alternatively, press RESET.
b. Logging facility. This applies only to analogue sensors
and allows the data reading from the device to be
stored in memory at regular time-intervals. It is
intended for use in conjunction with the ID2000 Series
support tool which runs on an IBM-compatible
personal computer. This program incorporates a
facility for retrieving this stored data and generating
an ASCII file, which can be imported into several
commonly-available spreadsheets.
i To set up a data log (panel keypad operation
only), answer the question about pulsing the
device’s LEDs. The question shown below is then
displayed:
ii Answer
. The display changes to that shown
below:
Sens. (n) Zone (n) (type)
1sec pulses, this device’s LEDS (
!!
!!
!/X)?
Sens. (n) Zone (n) (type)
Stop pulsing this device’s LEDS (
!!
!!
!/X)?
Sens. (n) Zone (n) (type)
Set up/amend DATA LOG (
!!
!!
!/X)?
(just
!!
!!
!to cancel logging)
interval (sec.:)
