12 LCD-160 Manual — P/N 51850:D2 10/07/2016
Section 4: Hardware
This section is intended as a basic inventory of components that can be used with the LCD-160.
4.1 Backboxes
These backboxes provide a surface or semi-flush mount enclosure for remote mounting. Use with
1/2” conduit in the provided knockouts. See Table 4.1 for dimensions.
ABS-2D/ABS-2DR A surface or semi-flush enclosure for remote mounting. Mounts an
LCD-160 directly to the enclosure’s hinged dress plate. The “D” version is black and slightly
deeper. The ABS-2D and ABS-2DR will not support the installation of the Annunciator Key
Switch or the Annunciator Phone Jack for Firefighters' Telephone. A trim ring option is available
for semi-flush mounting. Not for use in Canadian applications.
ABS-4D/ABS-4DR
A surface or semi-flush enclosure for remote mounting. Mounts an
LCD-160 and two annunciators directly to the enclosure’s hinged dress plate. This backbox will not
support the installation of the Annunciator Key Switch or the Annunciator Phone Jack for
Firefighters' Telephone.
ABF-2B A flush enclosure for remote mounting. Mounts an LCD-160 directly to the enclosure’s
dress plate. Not for use in Canadian applications.
ABF-4B A flush enclosure for remote mounting. Mounts an LCD-160 and two annunciators
directly to the enclosure’s dress plate.
CAB-4 Series Cabinet A surface or semi-flush enclosure for mounting one to four rows of
equipment plus batteries (up to two 25AH batteries). There are four different sizes available. The
separately ordered doors can be mounted on the left or the right side of the cabinet; reversible
hinges are provided so that this choice can be made in the field. Doors open a full 180 degrees and
have locks. A trim ring option is available for semi-flush mounting.
External measurements for each cabinet size are provided below. Refer to CAB-3/CAB-4 Series
Cabinet Installation Document (shipped with your cabinet) for specific mounting drawings and
dimensions.
NOTE: For Canadian Applications, only the ABS-2DC, ABS-4DC, and the CAB-4 Series
cabinets are approved for LCD-160 installation.
Part
Number
Height Width Depth Color
Optional
Trim Ring
ABS-2D
ABS-2DR
Box: 12.00" (30.48 cm.)
Door: 12.00" (30.48 cm.)
Box: 12.00" (30.48 cm.)
Door: 12.00" (30.48 cm.)
Box: 3.797" (9.644 cm)
Door: 1.250" (3.175 cm.)
Red, Black TR-ABS2D
ABS-4D
ABS-4DR
Box: 11.97" (30.40 cm)
Door: 11.97" (30.40 cm)
Box: 19.87" (50.47 cm)
Door: 19.87" (50.47 cm)
Box: 3.5" (8.89 cm)
Door: 1.25" (3.18 cm)
Red, Black N/A
ABF-2B Box: 9.938" (25.24 cm)
Door: 11.0" (27.94 cm)
Box: 9.188" (20.80 cm)
Door: 10.375" (26.35 cm)
Box: 3.750" (9.53 cm)
Door: 0.75" (1.9 cm)
Black N/A
ABF-4B Box: 9.937" (25.240 cm) Box: 17.750" (45.085 cm) Box: 2.500" (6.350 cm) Black N/A
CAB-4 Series (without doors)
A-Size
(1 row)
20.125 in (51.12 cm) 24.125 in (61.28 cm) 5.218 in (13.25 cm) TR-A4
B-Size
(2 rows)
28.625 in (72.70 cm) 24.125 in (61.28 cm) 5.218 in (13.25 cm) TR-B4
Table 4.1 Backbox Sizing Guide
