LCD-160 Manual — P/N 51850:D2 10/07/2016 39
Service Screens Screen Displays
Figure 9.10 Multiple Events List Display Screen
Soft Keys
FIRST EVENT - Press this key to display the first active of the type shown on line one. If the soft
key
SCROLL BACK is displayed, it will change to MAIN MENU.
SCROLL BACK (MAIN MENU) - Press this key to scroll backwards through an event list. This
option will change to
MAIN MENU when the FIRST EVENT key is pressed.
9.3 Service Screens
9.3.1 Version Information
Software version information may be displayed by pressing the LAMP TEST key on the keyboard for
more than three seconds. The following screen will appear while the
LAMP TEST key is pressed.
Figure 9.11 Version Screen
ACKNOWLEDGED FIRE ALARM
ELEVATOR LOBBY EAST WING
FIFTH FLOOR Z005 SMOKE(PHOTO)
11:57:45A TUE JAN 12, 2016 N112L03D052
FIRE ALARM:0001 OF 0003
2 ALM 6FLR ELEVATOR LOBBY EAST WING
3 ALM 5FLR ELEVATOR LOBBY EAST WING
1 SUP MAIN ELEVATOR LOBBY EAST WING
2 SUP 6FLR ELEVATOR LOBBY EAST WING
1 TBL GARAGE 4 PKING LV4
2 TBL GARAGE 4 PKING LV3
1 DIS MAIN ELEVATOR LOBBY EAST WING
ALARM:0003 SUPERVISORY:0002 TROUBLE:0002
12:06:32P TUE JAN 15, 2008
FIRST EVENT MAIN MENU
DISPLAY
BOOT: 001.000.048 JUN 19 2008 15:45
APP: 001.000.149 JUL 9 2008 05:45
DBASE LAST CHANGED: JUL 19 2008 16:02
NODE: 081
The custom panel label appears on Line 7
REMOTE DISPLAY: 32
The custom RD label appears on Line 10
