38 LCD-160 Manual — P/N 51850:D2 10/07/2016
Screen Displays Operating Screens
Line 14 displays current counts of off-normal events in three categories: ALARM, SUPERVISORY, and
TROUBLE. The counts include both acknowledged and unacknowledged events.
Pressing one of the Scroll Display fixed function keys will cause the first event of that type (e.g.,
alarm, trouble, etc.) to display at the top, and subsequent events of that type to display in sequence
below it. It will also change the
MAIN MENU soft key to SCROLL BACK. Press the key again to
begin scrolling. If there are no events of the type denoted by the Scroll Display key, pressing the
key will have no effect. Pressing the
SCROLL BACK soft key will scroll the list back one event.
If an unacknowledged or off-normal event occurs while this screen is active, lines one through four
will display the event in the event reporting format (See “Event Reporting Format” on page 25).
Line five will read
PRESS ANY KEY. Pressing any key will return the display to the “Event
Counts” screen.
With Fire as the highest priority: With MNS as the highest priority:
USA Event Order Canada Event Order USA Event Order Canada Event Order
Fire Fire MN Alarm
CO Alarm CO Alarm Fire Fire
MN Alarm CO Alarm CO Alarm
CO Pre-alarm CO Pre-alarm CO Pre-alarm CO Pre-alarm
Security — Security —
Supervisory Supervisory MN Supervisory
MN Supervisory Supervisory Supervisory
Trouble Trouble MN Trouble
MN Trouble Trouble Trouble
Pre-alarm Pre-alarm Pre-alarm Pre-alarm
Disabled Disabled Disabled Disabled
Note: Fire/MNS priority dependent on fire panel programming. Refer to the fire panel programming manual
for additional information.
NOTE: Pressing the ACKNOWLEDGE hard key when there is an off-normal event will only return the
display to the “Event Counts” screen. It will not acknowledge the off-normal event. An off-normal event
can only be acknowledged from the “Event Counts” screen.
