42 LCD-160 Manual — P/N 51850:D2 10/07/2016
Screen Displays Service Screens
Figure 9.16 Download Strings Screen
9.3.7 Application Corrupt Screen
During power-up, the panel checks the application code. If the code is corrupt, the panel cannot
proceed, and the following screen is displayed. The user must use Ve r i F i r e To o l s to download the
application code. Usually this screen results from a power interrupt during a critical period of
application download. The Trouble LED will flash and the piezo (if enabled) will sound while this
screen is in effect.All corrupt images will activate the corresponding system trouble. Pressing the
Trouble Scroll button will scroll through all system troubles.
Figure 9.17 Application Corrupt Screen
TROUBLE
LOADING..NO SERVICE
A01
LCD-160 BOOTLOADER
LCD-160 DOWNLOAD MENU
UPDATING LCD-160 STRINGS
DOWNLOADING...
76%
TROUBLE
APPLICATION CORRUPT
A01
LCD-160 BOOTLOADER
TUE JAN 12, 2016
PLEASE DOWNLOAD NEW APPLICATION CODE
