20 RP-2001 Series Manual — P/N 52985:D5 1/26/2017
Installation Backbox Mounting
T
B
6
S
W
1
mounting studs
mounting slots
mounting tabs
mounting holes
grounding stud:
attach solid earth
ground wire (refer to
Figure 2.4 on page 23)
Main Circuit Board on Chassis
Backbox
Figure 2.1 Chassis Mounting in Backbox
rp2001brdinbox.wmf
mounting slots
