96 RP-2001 Series Manual — P/N 52985:D5 1/26/2017
Appendix B: FACP Configuration Templates
The RP-2001/E has been provided with preprogrammed templates which allow the user to quickly
configure the FACP [refer to “FACP CONFIG (Application Templates)” on page 51]. The user also
has the option to reprogram selected portions of the template for customized applications. The
following pages of this appendix describe the programming for each of the templates.
Important! Each Template has been programmed with specific Input Zone Types and Output
Circuit Types. If the FACP is configured with one of the preprogrammed Templates, the user must
ensure that the devices connected to each Input Zone and Output Circuit are compatible with the
programmed types. (The user can reprogram the circuit types if desired).
NOTE: The RP-2001/E Pre-Action/Deluge Control Panel can be configured using
preprogrammed Templates 1 through 7.
