42 RP-2001 Series Manual — P/N 52985:D5 1/26/2017
Installation ANN-BUS Devices
Setting Printer Options
Refer to the documentation supplied with the PRN-6 printer for instructions on using the printer
menu controls. Set the printer options (under the menu area) as shown in the following table:
2.7.5 N-ANN-I/O LED Driver Module
The N-ANN-I/O is an LED driver module that can be used in a wide variety of applications,
including as an interface with most customized graphic annunciators. The N-ANN-I/O can drive up
to 40 LEDs. The following sections describe hardware installation. Refer to the section
titled“ANN-BUS” on page 66 for programming information.
Option Setting Option Setting
Font HS Draft CPI 10CPI
LPI 6 LPI Skip 0.5
ESC Character ESC Emulate Epson FX-850
Bidirectional Copy ON I/O
CG-TAB Graphic Buffer 40K
Country E-US ASCII Serial
Auto CR OFF Baud 9600 or 2400
Color Option Not Installed Format 7 Bit, Even, 1 Stop
Formien Protocol XON/XOFF
Lines 6LPI=60 Character Set Standard
Standard Exec 10.5 SI.Zero On
Auto LF On
PAPER
BIN 1 12/72”
BIN 2 12/72”
SINGLE 12/72”
PUSH TRA 12/72”
PULL TRA 12/72”
PAP ROLL 12/72”
Table 2.3 PRN-6 Setup Options
