RP-2001 Series Manual — P/N 52985:D5 1/26/2017 97
Template 1: Single Hazard - 3 Zone FACP Configuration Templates
B.1 Template 1: Single Hazard - 3 Zone
Table Legend:
X = direct correlation between Input Zone and Output Circuit (input zone activation will turn on
corresponding output circuit).
Input Zone Types:
• Zone 1 = 2-wire smoke
• Zone 2 = Fire
• Zone 3 = Waterflow - no waterflow delay since Waterflow Delay Timer is set to 0
• Zone 4 = Manual Release
• Zone 5 = Pull Station
• Zone 6 = Supervisory
Output Circuit Types:
• Output 1 = Alarm NAC, silenceable, coded for steady on
• Output 2 = Waterflow NAC - no waterflow delay since Waterflow Delay Timer is set to 0,
silenceable, coded for steady on
• Output 3 = Release Solenoid 1 (unsupervised for shorts)
• Output 4 = Supervisory Bell NAC, silenceable, coded for steady on
Timers
• Soak Timer 1 - set for 10 minutes
• Soak Timer 2 - set for 10 minutes
• Waterflow Delay Timer - set for 0 seconds
• AC Loss Delay Timer - set for 2 hours
Operation
• Activation of Input Zone 1 (2-Wire Smoke) or Zone 2 (Fire) or Zone 4 (Manual Release) or
Zone 5 (Pull Station) will operate the Alarm NAC Output #1 and Release Solenoid 1 Output
#3. Release Solenoid 1 will turn off water release following time-out of the 10 minute Soak
Timer 1
• Activation of Input Zone 3 (Waterflow) will operate the Waterflow NAC Output #2. There is
no FACP initiated delay in activation since the Waterflow Delay Timer is set to 0 seconds
• Activation of Input Zone 6 (Supervisory) will operate the Supervisory Bell NAC Output #4
Template 1: SINGLE HAZARD - 3 ZONE
INPUT ZONES
123456
OUTPUT CIRCUITS
2-WIRE SMOKE FIRE WATERFLOW
MANUAL
RELEASE
PULL
STATION
SUPV.
#1 ALARM NAC
XX XX
#2 WATERFLOW NAC
X
#3 RELEASE SOLENOID 1
XX XX
#4 SUPV. BELL NAC
X
