Honeywell UDC330E User Manual

Position Proportional Calibration
102 UDC3300 Expanded Model: DC330E User Manual 5/00
Table 9-1 Calibration Procedure
Step Operation Press Action
1
Enter
Calibration
Mode
SETUP
until you see
Upper Display: CALIB
Lower Display: POS PROP
2
Set Motor
Traverse
Time
FUNCTION
LOOP 1/2
Until you see
Upper Display: (A value)
Lower Display: MTR TIME
NOTE: This is the time it takes the motor to travel from 0
to 100%.
3
▲ or ▼
until the proper motor stroke time is reached (see the
motor specs or measure the time)
Range of setting = 5 to 1800 Seconds
4
Select
Automatic or
Manual
Calibration
FUNCTION
LOOP 1/2
Until you see
You can calibrate the controller output manually or let the
controller calibrate the output automatically.
If the slidewire has never been calibrated, you must use
DO AUTO first. In the “Automatic Calibration Mode” (DO
AUTO), the controller relays automatically move the motor
in the proper direction.
If desired, however, the motor may be manually
positioned to 0% and 100% positions. Disconnect the
relay wires. Use DO MAN. In the “Manual Calibration
Mode” (DO MAN), the motor does not move. Instead, the
existing 0% and 100% values may be changed with the
▲ or ▼ key.
5
▲ or ▼
to select automatic or manual calibration.
Upper Display: DO AUTO or DO MAN
Lower Display: POS PROP
If you select… Then…
DO AUTO go to Step 6
DO MAN go to Step 8
ATTENTION
When calibration is terminated, this
selection reverts to DISABL.

Honeywell UDC330E Specifications

General

Category	Controller
Type	Universal Digital Controller
Mounting	Panel Mount
Input Types	Thermocouple, RTD, mA, V
Output Types	Relay, mA, V
Control Mode	On/Off, PID
Display	Dual 4-digit LED
Power Supply	100-240 VAC
Communication Protocols	RS-485, Modbus
Temperature Range	Depends on input type
Operating Temperature	0 to 50 °C
