6.1.9 Application 1-24 – Variant 4
Application 1–24 – variant 4, operates with two DOM with amplifiers 2XD250 or 2XD400.
Fig. 31: Overview application 1-24 – Variant 3
PA
DOM 1
DOM 2
Connection
Board
583369
3
1
1
PA
DOM 1
DOM 2
Connection
Board
583369
3
1
1
Fig. 32: Input / output connection
The spare connections on the connection board must not be used to connect additional amplifiers.

Input cable DOM amplifier
(0,5 m, green)  audio frequency (AF), control to power amplifier (PA)
583491 or 583491A

Output cable 1-24 (2 channels each up to 24 lines) 583432




