Installation Instruction VARIODYN
®
D1 System
FB 798663.GB0 / 05.19 5
Responsibility of the Operator
In addition to the standard-compliant design, a stipulation of the minimum requirements and functions between
the operator of the system and the responsible authorities is required for the construction and operation of a VAS
system.
Here the local standard as the TRVB 158 S in Austria (AWS/ENS) and the DIN VDE 0833-4 in Germany have to
be followed if the system is controlled automatically by a fire alarm control panel.
Basic stipulations
• Definition of the safety level (I, II, III)
• Scope of public address system
• Alarm areas, detection areas, fire compartments
• Site of the voice alarm control panel (VACP), configuration levels, and accessibility
• Need for fire microphones and number of terminals, as well as their usability
• Alarm organisation and specification of the announcement texts
Related Documents
These installation instructions are intended for qualified technicians or trained installers and contain all of the
important information needed for assembling and installing VARIODYN
®
systems. Additional information on
assembly, operation, commissioning, and configuration can be found in the following documents:
Part No. Name
798661.GB0 System design principles for Voice Alarm Systems (VAS)
798662.GB0 Operating Instructions for the VARIODYN
®
D1 System
798664.GB0 Commissioning Instructions for the VARIODYN
®
D1 System and VARIODYN
®
D1 Comprio
798678 Commissioning Instructions VARIODYN
®
D1 Networking
798683.GB0 Installation Instruction VARIODYN
®
D1 devices and accessories
Additional and updated Information
The described features, specifications and product related information in this manual correspond to
the date of issue (refer to date on the front page) and may differ due to modifications and/or
amended Standards and Regulations of the System design, Installation and Commissioning.
Updated information and declaration of conformity are available for comparison on the
www.esser-systems.comor www.hls-austria.com homepage.
®
D1-Systems are registered trademarks in Germany.
